high gain RIGID holographic screens HB: High Brightness,

The HB-FRESNEL-lens screens are screens for rear projection based on optical properties of Fresnel lenses* that capture the image and the focus directly toward the observer by ensuring a wide angle of vision, brilliance, clarity and uniformity of images and avoiding dispersions and hot spots.

The
rear projection HB FRESNEL screen consists of thousands of concentric lenses each of which has a specific and different angles of curvature to capture the light of the projector and forwards it directly to the observer.

The
projector-screen distance may therefore be much smaller than required for traditional holographic screen.


In applications requiring high resolution images as in black control rooms, simulators, conference room, HB FRESNEL rear projection screens ensure exceptional and amazing results!

* Fresnel lenses are "flat" lenses that retain all the focusing features of the traditional lenses' curvature but with minimum size and weight. The result is obtained by cutting the profile of a traditional spherical lens in a series of concentric rings: the curvature is reduced to a flat surface but preserves all the dioptric power of the curvature.




DOWNLOAD catalogue:
CIMEX HB FRESNEL LENS

HB FRESNEL - show roomHB FRESNEL - fairHB FRESNEL - fairHB FRESNEL - fairHB FRESNEL - fashion showHB FRESNEL - fairHB FRESNEL - black control room

TECHNICAL DATA

SCREEN DOMENTIONS

67"

72"

84"

90"

96"

100"

120"

125"

140"

150"

160"

height [mm]

1060

1123

1305

1422

1514

1575

1880

1925

2194

2346

2500

width[mm]

1395

1488

1732

1880

2001

2083

2489

2559

2905

3108

3312

thickness[mm]

5.5

5.5

5.5

5.5

5.5

5.5

5.5

7

7

7

7

weight[kg]

8

9

12

14

20

21

30

32

58

66

75

AREA PROIETTABILE

hieight[mm]

1022

1097

1280

1396

1463

1524

1828

1874

2134

2286

2440

width[mm]

1358

1463

1706

1854

1950

2032

2438

2508

2845

3048

3252

GAIN

3

3

3

3

3

3

3

3

3

3

3

projector-screen distance

1500-2500

2200-3300

2200-3300

2200-3700

2300-4500

2600-4500

2600-4900

2600-5200

3000-5000

3000-5000

3000-5000

focal distance

850

1800

1800

1800

1800

1800

2800

2800

3500

3500

3500

Fresnel PITCH [mm]

0.25

0.33

0.33

0.33

0.33

0.33

0.33

0.33

0.8

0.8

0.8

half gain angle - horizontal

33°

33°

33°

33°

33°

33°

33°

33°

33°

33°

33°

half gain angle - vertical

33°

33°

33°

33°

33°

33°

33°

33°

33°

33°

33°



MATERIAL

acrylic

acrylic

acrylic

acrylic

acrylic

acrylic

acrylic

acrylic

acrylic

acrylic

acrylic

COLOUR

dark

dark

dark

dark

dark

dark

dark

dark

dark

dark

dark

MATT surface

yes

yes

yes

yes

yes

yes

yes

yes

yes

yes

yes

ANTI-REFLECTIVE surface

yes

yes

yes

yes

yes

yes

yes

yes

yes

yes

yes

ON REQUEST:
We can produce HB - FRESNEL lens with any itermediate dimentions or ratio or with different forms.
